High Efficiency Radial Piston Motor with Five Cylinders

We have developed and sold this High Efficiency Radial Piston Motor with Five Cylinders to European, American and Southeast Asian market for decades. We have a professional product design and manufacture team to guarantee the quality and delivery time for customers. We are expecting to be your best partner in China.

Model:XHS2

Send Inquiry

Product Description

1. Product Introduction of High Efficiency Radial Piston Motor with Five Cylinders

We have manufactured this High Efficiency Radial Piston Motor with Five Cylinders since 2006. We have a lot of experience and advanced equipment to guarantee the quality and delivery time. This High Efficiency Radial Piston Motor with Five Cylinders can be used in closed or open circuit and driven by piston pumps or vane pumps.Our commission is to serve our users and purchasers with greatest good quality and aggressive portable digital items for ODM Factory China Rexroth Motors Hydraulic Piston Pump Motor Good Price High Efficiency for Excavator, We invitations you and your company to prosper along with us and share a vibrant long term in worldwide current market. ODM Factory China Motor, After years of development, now we have formed strong ability in new product development and strict quality control system to ensure excellent quality and service. With the support of many long term cooperated customers, our solutions are welcomed all over the world.

High Efficiency Radial Piston Motor with Five Cylinders


2.Product Parameter (Specification) of High Efficiency Radial Piston Motor with Five Cylinders

XHS2

Unit

200

250

300

350

420

500

600B

630B

Displacement

ml/r

192

251

304

346

424

492

565

623

Specific torque

Nm/MPa

30.5

39.9

48.3

55

67.4

78.2

89.8

99

Pressure rating

MPa

25

25

25

25

25

25

25

25

Peak pressure

MPa

31.5

31.5

31.5

31.5

31.5

31.5

31.5

31.5

Peak power

kW

59

59

59

59

59

59

59

59

Torque rating

Nm

680

890

1080

1225

1505

1745

2005

2210

Peak torque

Nm

810

1060

1285

1460

1790

2075

2385

2630

Speed rating

r/min

400

400

360

360

300

280

250

220

Cont. speed

r/min

500

500

450

450

380

350

320

280

Max. speed

r/min

760

760

700

700

700

650

650

550

Weight

kg

51

51

51

51

51

51

51

51


3.Product Feature And Application

This is a fixed displacement and High Efficiency Radial Piston Motor with Five Cylinders. This high mechanical and volumetric efficiency piston motor has excellent cavitation resistance. These motors can provide hydraulic power for winches, cranes, trucks and mechanical actuators. They are widely applied to construction, ship deck and mining industrial.


4.Product Details of High Efficiency Radial Piston Motor with Five Cylinders

This High Efficiency Radial Piston Motor with Five Cylinders is actuated by swing cylinder and can work under high pressure condition. We supply a range of displacements of motor for customers. They can select motors according to their actual demand.


5.Product Qualification of High Efficiency Radial Piston Motor with Five Cylinders

Our products are certificated by ISO, CCS, DNV, BV, LR. Each product is delivered with a quality certification.


6.Deliver,Shipping And Serving of High Efficiency Radial Piston Motor with Five Cylinders

We can guarantee to provide a short delivery time and high performance products to our customers. We also provide one year warranty.
