Hydraulic Mechanical Actuator for Crane Winch
  • Air ProHydraulic Mechanical Actuator for Crane Winch
  • Air ProHydraulic Mechanical Actuator for Crane Winch

Hydraulic Mechanical Actuator for Crane Winch

We have developed and sold this Hydraulic Mechanical Actuator for crane winch to European, American and Southeast Asian market for many years. We have a professional product design and manufacture team to guarantee the quality and delivery time for customers. Welcome to buy Hydraulic Mechanical Actuator for crane winch from us. Every request from customers is being replied within 24 hours.

Send Inquiry

Product Description

1.Product Introduction of Hydraulic Mechanical Actuator for Crane Winch

We have manufactured this Hydraulic Mechanical Actuator for crane winch since 2006. We have a plenty of experience and advanced equipment to guarantee the quality and delivery time. This Hydraulic Mechanical Actuator for crane winch can transfer hydraulic energy to mechanical energy with high efficiency.

Hydraulic Mechanical Actuator for Crane Winch


2.Product Parameter (Specification) of Hydraulic Mechanical Actuator for Crane Winch

XHM6

Unit

6-400

6-450

6-500

6-600

6-650

6-700

6-750

Displacement

ml/r

397

452

490

593

660

706

754

Pressure rating

MPa

20

20

20

20

16

16

16

Peak pressure

MPa

30

30

30

30

25

25

25

Torque rating

Nm

1265

1440

1562

1890

1680

1800

1921

Specific torque

Nm/MPa

63

72

78

95

105

112

120

Max Power

Kw

52

52

52

52

52

52

52

Max. speed

r/min

500

480

450

420

400

380

350

Weight

kg

57

57

57

57

57

57

57


3.Product Feature And Application

This is a fixed displacement and Hydraulic Mechanical Actuator for crane winch. This Hydraulic Mechanical Actuator for crane winch has excellent cavitation resistance. These motors can provide hydraulic power for winches, cranes, trucks and mechanical actuators. They are widely applied to construction, ship deck and mining industrial.


4.Product Details of Hydraulic Mechanical Actuator for Crane Winch

This Hydraulic Mechanical Actuator for crane winch is actuated by pistons and can work under high pressure condition. We supply a range of displacements of motor for customers. They can select motors according to their actual demand.


5.Product Qualification of Hydraulic Mechanical Actuator for Crane Winch

Our products are certificated by CCS, DNV, BV, LR. Each product is delivered with a quality certification.


6.Deliver,Shipping And Serving of Hydraulic Mechanical Actuator for Crane Winch

We can guarantee to provide a short delivery time and high performance products to our customers. We also provide one year warranty.
