Three Stage Planetary Gearbox

We have developed and sold this Three Stage Planetary Gearbox to European, American and Southeast Asian market for many years. We have a professional product design and manufacture team to guarantee the quality and delivery time for customers. Welcome to buy Three Stage Planetary Gearbox from us. Every request from customers is being replied within 24 hours.

Send Inquiry

Product Description

1.Product Introduction of Three Stage Planetary Gearbox

We have manufactured this Three Stage Planetary Gearbox since 2006. We have a plenty of experience and advanced equipment in manufacturing Three Stage Planetary Gearbox with the precisely helical teeth and balanced sun-gear shaft. This Three Stage Planetary Gearbox can transfer power from hydraulic motor to winch or rotatory machine.


2.Product Parameter (Specification) of Three Stage Planetary Gearbox

Model

Total Displacement(ml/r)

Rated torque(N.M)

Speed

(r/min)

Total

(efficency)

Hydraulic motor model

Planetary reducer model

Brake model

16Mpa

20Mpa

XHSC9-23000

23090

51744

64680

0-15

0.9-0.91

XHS9-4600

C9-5

XHZ9

XHSC9-28500

28270

63360

79200

0-15

0.9-0.91

XHS9-5700

C9-5

XHZ9

XHSC9-33000

33180

74342

92928

0-15

0.9-0.91

XHS9-6600

C9-5

XHZ9

XHSC9-38500

38480

86240

107800

0-15

0.9-0.91

XHS9-7700

C9-5

XHZ9

XHSC9-44000

44180

98982

-

0-15

0.9-0.91

XHS9-8800

C9-5

XHZ9

XHSC9-48400

48598

108880

-

0-15

0.9-0.91

XHS9-8800

C9-5.5

XHZ9

XHSC9-55000

55291

123904

-

0-15

0.9-0.91

XHS9-10000

C9-5.5

XHZ9

XHSC9-66000

66143

148220

-

0-15

0.9-0.91

XHS9-12000

C9-5.5

XHZ9


3.Product Feature And Application

This Three Stage Planetary Gearbox includes several planetary gear set which is made up of the sun gear (center gear), several planet gears and ring gear which rotate between each others. The load from the sun gear is distributed to multiple planetary gears which can either be applied to actuate an outer ring or a shaft or spindle. The center sun gear of Three Stage Planetary Gearbox can change a high speed and low torque input from hydraulic motors or electric motors to a low speed and high torque output. This Three Stage Planetary Gearbox is widely applied in wheel drives, slew drives, winch drives, track drives and cutter heads.


4.Product Details of Three Stage Planetary Gearbox

Our Three Stage Planetary Gearbox has a simple design which can transfer power from a motor to an output in high efficiency. Approximately 97% of the energy input is delivered as an output due to our advanced processing equipment and unique design. Our Three Stage Planetary Gearbox boasts low and high speed functions and unbeatable long-life performance, ideal for winches and mobile equipment.


5.Product Qualification of Three Stage Planetary Gearbox

Our products are certificated by CCS, DNV, BV, LR. Each product is delivered with a quality certification.


6.Deliver,Shipping And Serving of Three Stage Planetary Gearbox

We can guarantee to provide a short delivery time and high performance products to our customers. We also provide one year warranty.
