Radial Piston Motor with Five Cylinders

We have developed and sold this Radial Piston Motor with Five Cylinders to European, American and Southeast Asian market for many years. We have a professional product design and manufacture team to guarantee the quality and delivery time for customers. Welcome to buy Radial Piston Motor with Five Cylinders from us. Every request from customers is being replied within 24 hours.

Send Inquiry

Product Description

1.Product Introduction of Radial Piston Motor with Five Cylinders

We have manufactured this Radial Piston Motor with Five Cylinders since 2006. We have a plenty of experience and advanced equipment to guarantee the quality and delivery time. This Radial Piston Motor with Five Cylinders can transfer hydraulic energy to mechanical energy with high efficiency.

Radial Piston Motor with Five Cylinders


2.Product Parameter (Specification) of Radial Piston Motor with Five Cylinders

XHM11

Unit

11-700

11-800

11-900

11-1000

11-1100

11-1200

11-1300

Displacement

ml/r

714

792

904

992

1115

1247

1301

Pressure rating

MPa

20

20

20

20

20

20

16

Peak pressure

MPa

30

30

30

30

25

25

20

Torque rating

Nm

2260

2520

2860

3140

3551

3740

3080

Specific torque

Nm/MPa

113

126

143

157

177

187

197

Max Power

Kw

78

78

78

78

78

78

78

Max. speed

r/min

400

400

380

320

280

280

280

Weight

kg

94

94

94

94

94

94

94


3.Product Feature And Application

This is a fixed displacement and Radial Piston Motor with Five Cylinders. This Radial Piston Motor with Five Cylinders has excellent cavitation resistance. These motors can provide hydraulic power for winches, cranes, trucks and mechanical actuators. They are widely applied to construction, ship deck and mining industrial.


4.Product Details of Radial Piston Motor with Five Cylinders

This Radial Piston Motor with Five Cylinders is actuated by pistons and can work under high pressure condition. We supply a range of displacements of motor for customers. They can select motors according to their actual demand.


5.Product Qualification of Radial Piston Motor with Five Cylinders

Our products are certificated by CCS, DNV, BV, LR. Each product is delivered with a quality certification.


6.Deliver,Shipping And Serving of Radial Piston Motor with Five Cylinders

We can guarantee to provide a short delivery time and high performance products to our customers. We also provide one year warranty.
