1.Product Introduction of Electric Winch with Hidden Gearbox
We have manufactured this Electric Winch with Hidden Gearbox since 2006. Electric Winch with Hidden Gearbox consists of hydraulic motor, planetary reducer, disc brake, oil distributor and steel structure. Our Electric Winch with Hidden Gearbox has its own valve group which makes hydraulic system more simple and increases stability of the transmission device.
2.Product Parameter (Specification) of Electric Winch with Hidden Gearbox
|
Model |
Fast speed |
Middle speed |
Slow speed |
Diameter of steel cable(mm) |
Φ30 |
|
Pulling force of 1st layer(KN) |
72 |
100 |
100 |
Steel cable layers |
5 |
|
Cable speed of 1st layer(m/min) |
24 |
12 |
6 |
Cable capacity |
300 |
|
Model of electric motor |
JZ2-H-61-4/8/16 |
Model of reducer |
JZQ650-20-IV |
||
|
Power of electric motor(KW) |
30/30/22 |
Modulus of exposed gear |
m=10 |
||
|
Rotating speed of electric motor(rpm) |
1400/670/300 |
Speed ratio of exposed gear |
96/21 |
||
3.Product Feature And Application
This Electric Winch with Hidden Gearbox can lift and put down stably without empty hook vibrating and twice falling during hoisting. Our Electric Winch with Hidden Gearbox has advantages in high efficiency, low energy consumption, low noise and compact structure due to our accurate design proposal. This Electric Winch with Hidden Gearbox is widely applied in railway and automobile crane, ship, oil field, coal mine, port and other lifting equipment. Our design group can customize Electric Winch with Hidden Gearbox according to actual working condition.
4.Product Details of Electric Winch with Hidden Gearbox
Our company not only provides Electric Winch with Hidden Gearbox, but also provides whole hydraulic system and power source. The hydraulic motor, planetary gearbox and system of Electric Winch with Hidden Gearbox are designed and manufactured by our own factory. So the quality and delivery time can be controlled and guaranteed. We can also supply timely after-sale service and technique support.
5.Product Qualification of Electric Winch with Hidden Gearbox
Our products are certificated by CCS, DNV, BV, LR. Each product is delivered with a quality certification.
6.Deliver,Shipping And Serving of Electric Winch with Hidden Gearbox
We can guarantee to provide a short delivery time and high performance products to our customers. We also provide one year warranty.
